TrolMaster DSH-2 240V Humidity Device Station

TrolMaster DSH-2 240V Humidity Device Station

Price
Regular price $114.99
Regular price $114.99 Sale price
/
  • In stock, ready to ship
  • In stock
Shipping calculated at checkout.
  • Free shipping on all canadian orders over 149$*
  • Expert Technical Support
  • Official TrolMaster Dealer
  • Secure payments

The TrolMaster DSH-2 240V Humidity Device Station allows compatible TrolMaster environmental controllers to control 240V humidifiers and dehumidifiers by switching their electrical power ON and OFF.

The DSH-2 operates on 240 VAC, 50/60 Hz and provides a maximum output current of 10 A. For dehumidifiers, TrolMaster recommends using equipment drawing less than 7 A to reduce the risk of overload.

The module connects to the TrolMaster system through RJ12 communication and includes LED status indication, addressing and manual ON/OFF override. It is a simple plug-and-play solution for 240V humidity-control equipment in grow rooms and commercial cultivation facilities.
Why Buy From Hydroponique Pro?

Shop with confidence at Hydroponique Pro. We are an authorized Canadian retailer offering genuine TrolMaster products, expert technical support, and fast shipping across Canada.


✅ Canadian Hydroponics Specialists

📞 Real Technical Advice Before & After Your Purchase

📦 Carefully Inspected & Packed Orders

🔧 Genuine Products with Full Manufacturer Support

🌱 Trusted by Hobby & Commercial Growers Across Canada
Ask a question

This site is protected by hCaptcha and the hCaptcha Privacy Policy and Terms of Service apply.
Back to Trolmaster

Product overview

Control compatible 240V humidifiers and dehumidifiers directly from your TrolMaster environmental controller. The DSH-2 switches connected equipment ON and OFF according to your programmed humidity settings.

Key Features
  • Controls compatible 240V humidifiers and dehumidifiers
  • 240 VAC, 50/60 Hz input
  • Maximum output current: 10 A
  • Recommended for dehumidifiers drawing less than 7 A
  • RJ12 communication
  • LED status indicator
  • Manual ON/OFF override
  • Addressable plug-and-play device
Technical specifications

Product Type: 240V Humidity Device Station

Application: Humidification / Dehumidification

Input Voltage: 240 VAC, 50/60 Hz

Output Voltage: 100–240 VAC, 50/60 Hz

Maximum Output Current: 10 A

Recommended Dehumidifier Load: Less than 7 A

Operating Temperature: 32–122°F / 0–50°C

Operating Humidity: ≤90% RH

Communication: RJ12

Package Dimensions: 85 × 80 × 90 mm

Package Weight: 0.34 kg

Frequently asked questions

What does the DSH-2 control?

The DSH-2 controls compatible 240V humidifiers and dehumidifiers by switching their electrical power ON and OFF.

What is the difference between the DSH-1 and DSH-2?

The DSH-2 is intended for 240V humidity-control equipment, while the DSH-1 is typically used for standard-voltage equipment.

What is the maximum current rating?

The DSH-2 has a maximum output current of 10 A. TrolMaster recommends using dehumidifiers drawing less than 7 A to reduce the risk of overload.

Should I use a DSH-2 or HS-1?

Use the DSH-2 when a 240V device is controlled by switching its main electrical power. Use the HS-1 when the dehumidifier has a compatible low-voltage external humidistat input.

Can the DSH-2 control a humidifier?

Yes. It can control compatible humidifiers as well as dehumidifiers.

Compatible Controllers
