Water Connection
Place the unit on a level surface, such as a benchtop or floor. In an environment with little to no ventilation, place the unit in a centrallocation. In a ventilated area, place unit near the intake end. When the unit is in the desired location, connect a water supply to the female 6 mm / 1/4 inch inlet.See options as follows:
- Plumb directly to a water supply (6 mm / 1/4 inch plastictubing is preferred).- Connect to a garden hose fitting.
- Plumb to a storage tank higher than the fogging unit (gravity feed).
Suggested Maintenance
- Regularly clean the Reservoir Pan Assembly with soap and water to remove dirt and sediment. Use liquid bleach after cleaning, to sterilize any parts if algae was present.
- Periodically remove Strainer Screen and thoroughly flush. Also check to make sure the tapered pump/fan blade assembly is free of debris.
- Once every three months, check unit for calcium build-up. If build-up deposits are present, disconnect the water and take the unit outside. Pour calcium dissolving solvent (available in local hard-ware stores) in pan and operate unit outside to soften and remove the deposits.
- About once a year, remove the housing to check the SST Atom-izing Screen to be sure the slots are clear of mineral build-up. To clean, scrub with a calcium dissolving solvent.
- Unplug the appliance during filling and cleaning.
- Cleaning and user maintenance should not be made by children without supervision
- Multi-directional head
- H 15.75" x Ø 11.75"
- Output approx. 0.4 GAL/hour
- 173 CFM
- Industrial-grade motor
- Float valve
- 1.7L (0.45 GAL) reservoir
Optimum use with reverse osmosis water
-
-
-
