TrolMaster DSC-1 CO₂ Device Station – 120V

TrolMaster DSC-1 CO₂ Device Station – 120V

Price
Regular price $109.99
Regular price $109.99 Sale price $119.99
/
  • In stock, ready to ship
  • In stock
Shipping calculated at checkout.
  • Free shipping on all canadian orders over 149$*
  • Expert Technical Support
  • Official TrolMaster Dealer
  • Secure payments

The TrolMaster DSC-1 CO₂ Device Station is designed to control equipment used to increase and maintain CO₂ levels in a grow room.

Connected to a compatible TrolMaster controller, the DSC-1 can automatically turn a CO₂ regulator or CO₂ generator ON and OFF to maintain the programmed CO₂ setpoint. It can also be used with an exhaust fan as part of a CO₂ control or safety strategy.

The module features a 120V controlled outlet rated up to 10A, RJ12 plug-and-play connectivity, LED status indication and manual ON/OFF override.
Why Buy From Hydroponique Pro?

Shop with confidence at Hydroponique Pro. We are an authorized Canadian retailer offering genuine TrolMaster products, expert technical support, and fast shipping across Canada.


✅ Canadian Hydroponics Specialists

📞 Real Technical Advice Before & After Your Purchase

📦 Carefully Inspected & Packed Orders

🔧 Genuine Products with Full Manufacturer Support

🌱 Trusted by Hobby & Commercial Growers Across Canada
Ask a question

This site is protected by hCaptcha and the hCaptcha Privacy Policy and Terms of Service apply.

Product overview

The TrolMaster DSC-1 CO₂ Device Station provides automatic control of supplemental CO₂ equipment and exhaust devices. It features a 120V controlled outlet rated up to 10A, RJ12 connectivity, LED status indication and manual override.


*Requires the TrolMaster MBS-S8 CO₂ Sensor for CO₂ monitoring and control. The MBS-S8 is sold separately.

Key Features
  • Controls supplemental CO₂ equipment and exhaust devices
  • 120V controlled outlet
  • Maximum output current: 10A
  • Plug-and-play RJ12 connection
  • LED operating status indicator
  • Manual ON/OFF override
  • Addressable TrolMaster device module
  • Includes RJ12 cables and T-Splitter
Technical specifications

Model: DSC-1
Product Type: CO₂ Device Station
Input Voltage: 100–240 VAC, 50/60 Hz
Controlled Output: 120V
Maximum Output Current: 10A
Connection: RJ12
Operating Temperature: 32–122°F (0–50°C)
Operating Humidity: ≤90% RH
Package Dimensions: 85 × 80 × 90 mm
Gross Weight: 0.34 kg / 12 oz
Manual Override: Yes
Installation: Plug & Play

Frequently asked questions

Why add CO₂ to a grow room?

Adding CO₂ can help plants support faster photosynthesis and more vigorous growth when lighting, temperature, nutrition and other environmental conditions are properly controlled.

What is the TrolMaster DSC-1 used for?

The TrolMaster DSC-1 is a device station designed to automate CO₂-related equipment, such as CO₂ generators, regulators or compatible exhaust devices. It allows a compatible TrolMaster controller to turn connected equipment on or off based on conditions measured in the grow room.

Can the DSC-1 measure CO₂ levels by itself?

No. The DSC-1 is a device control station and does not have a built-in CO₂ sensor. It requires the TrolMaster MBS-S8 CO₂ Sensor to measure CO₂ concentrations in the grow room.

Is the TrolMaster MBS-S8 required to use the DSC-1?

Yes. The TrolMaster MBS-S8 is required for CO₂ monitoring and automatic CO₂ control. The MBS-S8 measures the CO₂ concentration and sends this information to the compatible TrolMaster controller, which can then control the DSC-1.

Is the MBS-S8 included with the DSC-1?

No. The TrolMaster MBS-S8 is sold separately. It must be added to the system when CO₂ monitoring and automatic CO₂ control are required.

What types of equipment can the DSC-1 control?

The DSC-1 can control different types of CO₂-related equipment through its 120V controlled outlet, including CO₂ injection equipment and certain exhaust devices, depending on the installation.

What is the maximum electrical load of the DSC-1?

The DSC-1 controlled outlet operates at 120V and supports loads up to 10A.

How does the DSC-1 connect to the TrolMaster system?

The DSC-1 uses an RJ12 connection to communicate with compatible TrolMaster controllers.

Can the DSC-1 be operated manually?

Yes. The DSC-1 includes a manual override function that allows the connected equipment to be activated manually when required.

Does the DSC-1 have a status indicator?

Yes. An integrated LED indicator provides a quick visual indication of the DSC-1 operating status.

Compatible Controllers & Sensors
